This sleeving works when cables already have connectors attached.
One cuts it with a hot knife so it does not unravel.
To finish one  can use cable ties (most often used)  or spiral wrap at
various spots to afford easy servicing and extra stability.
For a more permanent less easily serviced closure one can
also use a good quality electrical tape.

Tighter weave version.
Automotive Grade
More Info
1/8" -3/4"


Spiral wrap Example




Installation Tool (not necessary but easier.)

Selection

To find the correct size of braided sleeving for your application, begin by measuring the diameter of the cable bundle you'll be covering.
Depending on how you want the braided sleeving to fit around the cables, you can select a size in one of two ways.
If you're aiming for a snug fit, opt for braided sleeving with a diameter that's slightly smaller than that of your cables.
If a loose, flexible fit is what you're after, select sleeving with a diameter that is equal to or slightly larger than the diameter of your cables.
Whatever you choose, please take into account that braided sleeving shortens a bit when it expands…be sure to calculate accordingly!

Split Braid  (Ideally Cut with hot knife) reinforce with cable ties.


Dimensions: See inches to mm table below.

  1111111111111111

The fraction inches are rounded to 1/64 resolution.
For other values please use calculator at this url.

Millimeters (mm) Inches (")
(decimal)		 Inches (")
(fraction)
0.01 mm 0.0004 ″ 0 ″
0.1 mm 0.0039 ″ 0 ″
1 mm 0.0394 ″ 3/64 ″
2 mm 0.0787 ″ 5/64 ″
3 mm 0.1181 ″ 1/8 ″
4 mm 0.1575 ″ 5/32 ″
5 mm 0.1969 ″ 13/64 ″
6 mm 0.2362 ″ 15/64 ″
7 mm 0.2756 ″ 9/32 ″
8 mm 0.3150 ″ 5/16 ″
9 mm 0.3543 ″ 23/64 ″
10 mm 0.3937 ″ 25/64 ″
20 mm 0.7874 ″ 25/32 ″
30 mm 1.1811 ″ 1 3/16 ″
40 mm 1.5784 ″ 1 37/64 ″
50 mm 1.9685 ″ 1 31/32 ″
60 mm 2.3622 ″ 2 23/64 ″
70 mm 2.7559 ″ 2 3/4 ″
80 mm 3.1496 ″ 3 5/32 ″
90 mm 3.5433 ″ 3 35/64 ″
100 mm 3.9370 ″ 3 15/16 ″


Braided Sleeving…


Cutting


For weller iron you can also use and open flame carefully.

Hot Blade Soldering iron pencil method. A favorite method.


How to Select proper slit braided cable cover size.
